Rotary Microtome Manufacturer,Supplier and Exporter in India
Product Code : EL-BLE-10516
Quick Answer: The Rotary Microtome cuts sections from 1 micron, with a feed setting of 1–50 micron, a 120 mm heat-treated steel razor and a heavy base with a hinged cover over the mechanism.
Last updated: October 2026
Key Features
Heavy base with hinged cover protecting the interior mechanism, plus knife holder.
Each turn of the drive wheel advances the object holder through a ratchet, cone and inclined plane mechanism.
Device that automatically disengages the feed mechanism.
Feed indicator at the front, feed setting at the back: 1–50 micron.
120 mm razor of heat-treated steel, tested for microstructure.
Razor tilt adjustable up to 30 degrees on a reference scale.
Technical Specifications
| Specification | Value |
|---|---|
| Minimum thickness | 1 micron |
| Feed adjustment | 1–50 micron |
| Total feed excursion | 28 mm |
| Razor | 120 mm, heat-treated steel |
| Razor tilt | Up to 30 degrees, on reference scale |
| Overall size | 40 x 38 x 23 cm, with wooden case |
| Net weight | About 30 kg |
About This Product
On every full revolution of the drive wheel, the feed engages the teeth of a ratchet wheel and the object holder moves forward through a cone and inclined plane. Section thickness is chosen at the back of the instrument and read from the indicator at the front, and the razor angle can be set against its scale. Educational Lab Equipments can supply and export the Rotary Microtome to Bahrain, Papua New Guinea, Sudan, Saint Lucia and Mali.
Frequently Asked Questions
What section thicknesses can the Rotary Microtome cut?
The minimum thickness is 1 micron, and the feed can be set from 1 to 50 micron at the back of the microtome, with the feed indicator at the front.
What razor is included?
A 120 mm razor made from heat-treated steel and tested for microstructure is supplied. Its tilt angle can be adjusted up to 30 degrees on a reference scale.
How large and heavy is it?
The overall size is 40 x 38 x 23 cm with the wooden case, and the net weight is about 30 kg.
Related: Biology Lab Equipments, Hand and Table Microtome, Basic Plant Anatomy Slide.
For a quotation on the Rotary Microtome, contact Educational Lab Equipments.
