Coaxial Trinocular Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10983
Quick Answer: The Coaxial Trinocular Microscope has an inclined trinocular head, an Abbe N.A. 1.25 condenser and a built-in 6 V–20 W halogen light, with coarse and fine focusing from a single coaxial knob.
Last updated: November 2026
Key Features
Inclined trinocular head; body rotatable through 360 degrees.
Coaxial graduated mechanical stage moving the slide up to 50 x 75 mm.
Abbe N.A. 1.25 condenser, focusable by rack and pinion through 25 mm, with iris diaphragm and swing-out filter holder.
Built-in base halogen illumination, 6 V–20 W, with on/off switch and intensity regulator.
Plano-concave reflector set for daylight use.
Single coaxial focusing knob on a four-step gear reduction system.
Technical Specifications
| Specification | Value |
|---|---|
| Head | Inclined trinocular |
| Stage | Coaxial graduated mechanical, X-Y travel up to 50 x 75 mm |
| Condenser | Abbe N.A. 1.25, rack and pinion, 25 mm travel |
| Illumination | Built-in halogen, 6 V–20 W, intensity regulator |
| Daylight option | Plano-concave reflector |
| Focusing | Single coaxial knob, four-step gear reduction |
About This Product
One coaxial knob drives both coarse and fine focus through a four-step gear reduction, giving a smooth action. The halogen lamp in the base is dimmed with its own regulator and comes with power cord and plug, while the plano-concave reflector set lets the microscope work by daylight.
Frequently Asked Questions
How does focusing work on the Coaxial Trinocular Microscope?
Coarse and fine focus are both worked from a single coaxial knob, which runs on a four-step gear reduction system.
Is there a daylight option?
Yes. Besides the built-in 6 V–20 W halogen source with intensity regulator, a set of plano-concave reflectors is provided for working in daylight.
Which accessories suit the Coaxial Trinocular Microscope for teaching and documentation?
A Digital Eyepiece Camera for capturing images, a Stage Micrometer for calibration, and prepared slides such as Chromosomes (400x) and Bacteria (1000x, gram stain) for demonstrations.
Who is the Coaxial Trinocular Microscope suited to?
Laboratories and teaching departments that need to share or record what is seen, for example when one teacher demonstrates to a group, or when images are kept for reports and practical records.
Related: Microscopes, Coaxial Binocular Microscope, Trinocular Research Microscope, Digital Trinocular Microscope With LED Illumination.
For a quotation on the Coaxial Trinocular Microscope, contact Educational Lab Equipments.
