Digital Trinocular Microscope With LED Illumination Manufacturer,Supplier and Exporter in India
Product Code : EL-M-11018
Quick Answer: A trinocular microscope with a 3.0 megapixel digital eyepiece camera that fits the trinocular port through the included C-mount relay lens, giving four magnification levels from 40x to 1000x.
Last updated: October 2026
Key Features
3.0 megapixel digital eyepiece camera, USB 2.0 plug-and-play, with imaging software.
30-degree trinocular head rotating 360 degrees for reverse-position viewing or two observers.
Trinocular port can send the image to a digital camera or an LCD screen.
Reversed ball-bearing quadruple nosepiece with four colour-coded achromatic objectives.
Interpupillary distance adjustable from 54 mm to 76 mm.
Low-profile ball-bearing mechanical stage; low-set coaxial focus knobs with slip clutch.
Technical Specifications
| Specification | Value |
|---|---|
| Magnification | 40x to 1000x, four levels |
| Camera | 3.0 megapixel digital eyepiece, C-mount relay lens |
| Interface | USB 2.0 plug-and-play, imaging software |
| Head | Trinocular, 30-degree incline, 360-degree rotation |
| Interpupillary distance | 54 mm to 76 mm |
| Nosepiece | Reversed quadruple, ball bearing |
| Illumination | LED with intensity control |
About This Product
Pitched at senior high school and college level, this microscope lets one person view through the binocular eyepieces while the third port carries the camera image to a computer or an LCD screen for a group. The LED light lasts up to 60x longer than a traditional tungsten bulb and stays cool to the touch.
Frequently Asked Questions
What camera is included with the Digital Trinocular Microscope With LED Illumination?
A 3.0 megapixel digital eyepiece camera, fitted to the trinocular port with the included C-mount relay lens. It connects by USB 2.0 plug-and-play and comes with imaging software.
What level of study is this microscope intended for?
Senior high school and college use, with four magnification levels from 40x to 1000x.
Can two people use it at once?
Yes. The 30-degree trinocular head rotates 360 degrees, allowing reverse-position viewing and observation by two people.
