Dissecting Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10375
Quick Answer: The Dissecting Microscope has a heavy round base for stability and a jointed revolving arm that carries the magnifying lens over the whole stage. Focusing is by rack and pinion, and detachable rests on both sides steady the hands during fine dissection.
Last updated: October 2026
Key Features
Heavy round base.
Jointed revolving arm moves the magnifying lens over the full stage area.
10x and 20x eyepieces.
Stage 85 x 75 mm with glass plate.
Plano-concave lens in a fork for reflecting light.
Sensitive rack and pinion focusing.
Technical Specifications
Specification
Value
Base
Heavy, round
Optics
10x and 20x eyepieces
Stage
85 x 75 mm with glass plate
Illumination
Plano-concave lens in fork, for light reflection
Focusing
Rack and pinion
Arm
Jointed, revolving
Hand rests
Detachable, both sides of stage
About This Product
Because the lens swings across the stage on its arm, a specimen can be scanned from edge to edge without being disturbed. The detachable rests support the hands during delicate work, and the fork-mounted reflector directs light onto the specimen.
Frequently Asked Questions
What magnification options are provided?
The optics consist of 10x and 20x eyepieces.
What size is the stage?
The stage measures 85 x 75 mm and has a glass plate.
Are hand rests included?
Yes. Detachable rests on either side of the stage support the hands during fine dissection.
