Air Cooled Transformer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11265
Quick Answer: The Air Cooled Transformer has copper coils with tappings on both primary and secondary sides, wound on a laminated CRGO core of silicon stampings and housed in a powder-coated MS box.
Last updated: October 2026
Key Features
Copper primary and secondary coils wound with tappings.
Laminated core of CRGO-grade silicon stampings.
Coils vacuum pressure impregnated for high insulation strength.
Insulated terminals, marked to identify the different primary and secondary connections.
MS box with powder coating against rust.
Technical Specifications
Specification
Value
Cooling
Air
Core
CRGO laminated silicon stampings
Windings
Copper, tapped on primary and secondary
Impregnation
Vacuum pressure
Housing
MS box, powder coated
About This Product
With tappings on both windings, one transformer gives several connection options, each identified at the marked, insulated terminals. The core and coils are air cooled and enclosed in a powder-coated MS box that resists rust. Educational Lab Equipments can supply and export the Air Cooled Transformer to Lesotho, Haiti, Iceland, Kuwait and Portugal.
Frequently Asked Questions
What is the core of the Air Cooled Transformer made of?
It is a laminated core made from CRGO-grade silicon stampings.
How are the windings insulated?
The primary and secondary copper coils are impregnated under vacuum pressure for high insulation strength.
