D.C. Motor Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11233
Quick Answer: A laboratory DC motor offered in shunt, series or compound windings at 220V, 380V or 440V, from 0.5 HP to 10 HP, with a permeability steel yoke.
Last updated: October 2026
Key Features
Shunt, series or compound windings.
Ratings of 220V, 380V or 440V, from 0.5 HP to 10 HP.
Yoke of permeability steel; armature stamping of silicon.
Vacuum pressure impregnated field windings and armature; insulated copper conductors.
Dynamically balanced rotor, loading pulley and armature; large bearings; cooling fans.
Base frame with C.P. handle, heavy duty bolt and dial-type spring for machine readings.
Technical Specifications
Specification
Value
Voltage
220 V, 380 V, 440 V
Power
0.5 HP to 10 HP
Winding types
Shunt, series, compound
Yoke
Permeability steel
Conductors
Copper, insulated
Cooling
Fan cooled
About This Product
Choosing between shunt, series and compound windings lets a lab cover each type of DC motor with the same machine design. Readings are taken from the dial-type spring mounted on the base frame, and the terminal box has every terminal fixed in place.
Frequently Asked Questions
Which winding types are available for the D.C. Motor?
Shunt, series and compound types, in ratings of 220V, 380V and 440V from 0.5 HP to 10 HP.
How are readings taken on the machine?
The base frame has a C.P. handle, a heavy duty bolt and a dial-type spring that help in taking accurate readings.
