RF Trainer + 23 Modules + 500MHz Spectrum Analyser TG Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11286
Quick Answer: This RF trainer pairs a set of RF experiment modules with a 10 MHz to 500 MHz spectrum analyser that includes a tracking signal source for network analysis and a built-in frequency counter.
Last updated: October 2026
Key Features
Spectrum analyser covering 10 MHz to 500 MHz with 100 kHz resolution.
Tracking signal source for network analysis, and RF modules for experiments.
Built-in frequency counter; centre frequency on a 4-digit LED display with variable control.
Input range -85 dBm to 20 Vp-p, 50 ohm BNC input.
Horizontal scan up to 50 MHz/div, continuous.
CRO outputs: linear X and log Y, both on BNC.
Technical Specifications
Specification
Value
Frequency range
10 MHz to 500 MHz
Resolution
100 kHz
Input range
-85 dBm to 20 Vp-p
Input impedance
50 ohm, BNC
Horizontal scan
Up to 50 MHz/div, continuous
Centre frequency
4-digit LED display, variable control
CRO outputs
Linear X, log Y (BNC)
About This Product
The analyser works whatever the waveform or modulation, so students can view the spectrum of each RF module's output without changing settings for the signal type. With the tracking signal source, the same instrument handles network analysis of the modules, and its linear X and log Y outputs can drive an external CRO.
Frequently Asked Questions
What frequency range does the spectrum analyser cover?
10 MHz to 500 MHz, with a resolution of 100 kHz and horizontal scan up to 50 MHz/div.
What signal levels can be measured?
The input range runs from -85 dBm up to 20 Vp-p, through a 50 ohm BNC input.
Can it be connected to an oscilloscope?
Yes. It has CRO outputs – linear X out and log Y out, both on BNC.
