Steam Boiler Trainer With Electrical Fault Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11276
Quick Answer: The Steam Boiler Trainer With Electrical Fault is built around an 18 kW electric boiler giving 50 psig steam at 52 lbs/hr, with a condensate feedwater system and the boiler controls on the rig.
Last updated: October 2026
Key Features
18 kW electric boiler with electric heating elements.
50 psig steam pressure at a flow rate of 52 lbs/hr.
Low water cut-off and level control, safety relief valve, blowdown valve and steam pressure gauge.
Automatic reset and manual reset operating controls, main on/off switch and pilot light.
Water sight glass with valves.
Condensate feedwater system: 9 gallon tank with sight glass, globe valve, make-up valve assembly, mounting legs and a high-pressure turbine-type pump on a 1/3 Hp motor.
Technical Specifications
Specification
Value
Boiler
Electric, 18 kW
Steam output
50 psig, 52 lbs/hr
Condensate tank
9 gallon
Condensate pump
High pressure, turbine type
Pump motor
1/3 Hp
About This Product
Students operate a working steam plant: the boiler raises steam, condensate collects in the tank and the pump returns it as feedwater, while the level control and low water cutoff watch the boiler water. Both automatic and manual reset operating controls are fitted, so the rig shows how each kind of control responds. Colleges and TVET centres in Comoros, Bangladesh, Samoa, Argentina, Iran and Kyrgyzstan can source the Steam Boiler Trainer With Electrical Fault from Educational Lab Equipments.
Frequently Asked Questions
What is the boiler rating?
An 18 kW electric boiler with electric heating elements, producing 50 psig steam at a flow rate of 52 lbs/hr.
What is in the condensate feedwater system?
A 9 gallon condensate tank with sight glass, a globe valve, a make-up valve assembly, mounting legs and a high-pressure turbine-type condensate pump driven by a 1/3 Hp electric motor.
