Transmission Line Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11288
Quick Answer: The Transmission Line Trainer uses a coaxial cable line with sine and square wave test generators and 10 test points to measure attenuation, input impedance, frequency characteristics and standing waves.
Last updated: October 2026
Key Features
Coaxial cable transmission line.
Sine wave and square wave test generators.
Variable impedance matching resistance.
10 test points with banana socket interconnections.
Experiments on line properties, attenuation, input impedance, frequency characteristics and standing waves.
220–230V AC, 50Hz, single-phase supply.
Technical Specifications
Specification
Value
Transmission line
Coaxial cable
Test generators
Sine wave, square wave
Test points
10
Interconnections
Banana sockets
Power supply
220–230V AC, 50Hz, 1 phase
About This Product
Signals from the built-in generators travel down the coaxial line, and readings taken at the 10 test points show how the line attenuates them along its length. Adjusting the impedance matching resistance lets students see how matching affects the standing waves on the line.
Frequently Asked Questions
What measurements can be made on the Transmission Line Trainer?
Line properties, line attenuation, input impedance of the line, frequency characteristics and standing waves, using sine and square wave test generators.
How are connections made?
Through banana sockets, with 10 test points on the coaxial cable line.
