Wind Energy Modular Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-ETS-11559
Quick Answer: The Wind Energy Modular Trainer uses a 160 W, 12 V wind turbine with a battery and a 12 V, 32 A battery control module, so students can build both DC and AC wind energy installations.
Last updated: October 2026
Key Features
160 W, 12 V wind turbine, with anemometer and wind direction sensor on a stand.
Battery with a 12 V, 32 A battery control module for regulating and charging.
12 V load module: 20 W dichroic and 3 W LED lamps with independent switches.
Mains voltage load module: 35 W dichroic and 3 W LED lamps.
DC to AC converter with sinusoidal output at mains voltage, 300 W average power.
Measurement module for wind speed and direction, current, voltage and power.
Technical Specifications
| Specification | Value |
|---|---|
| Wind turbine | 160 W, 12 V |
| Battery control module | 12 V, 32 A |
| DC load module | Two 12 V lamps: dichroic 20 W, LED 3 W |
| AC load module | Two mains voltage lamps: dichroic 35 W, LED 3 W |
| DC to AC converter | Sinusoidal output at mains voltage, 300 W average |
| Measurement module | Wind speed, wind direction, current +/-15 A, voltage up to 30 V, power up to 1000 W |
| Wind sensors | Anemometer and wind direction sensor on a stand |
About This Product
The course starts with installing and testing the turbine and anemometer and connecting them to the trainer. Students then regulate and charge the battery, wire a direct current installation with the 12 V lamps, add the converter for an alternating current installation, and finally put together the complete wind energy system.
Frequently Asked Questions
Does the trainer cover both AC and DC systems?
Yes. Students set up a direct current installation with 12 V lamps and an alternating current installation through the DC to AC converter, which gives a sinusoidal output at mains voltage with 300 W average power.
How is the battery managed?
A battery control module rated 12 V, 32 A handles battery regulation and charging from the wind turbine.
Related: Energy Training System, Wind Energy Modular Trainer With Connection, Photovoltaic Trainer.
For a quotation on the Wind Energy Modular Trainer, contact Educational Lab Equipments.
