Fatigue Testing Machine Manufacturer,Supplier and Exporter in India
Product Code : EL-MTM-11572
Quick Answer: The Fatigue Testing Machine runs cylindrical steel test bars on an electric motor drive and loads them through a movable support, threaded spindle and hand wheel, with a spring balance showing 0–300 N. A stop switch in the movable support shuts the machine down automatically when a bar fractures.
Last updated: October 2026
Key Features
Loading device with movable support, threaded spindle with hand wheel and spring balance, 0–300 N.
Electric motor drive, 2,800 rpm and 0.37 kW.
Contactless inductive speed sensor.
Electronic load cycle counter with 8-digit display, switchable to show speed.
Automatic shut-down on test bar fracture via a stop switch in the movable support.
3 sets of cylindrical Ck35 steel test bars in 3 shapes, including special shapes for notching and surface finish.
Technical Specifications
| Specification | Value |
|---|---|
| Motor speed | 2,800 rpm |
| Motor output | 0.37 kW |
| Load | 0–300 N |
| Test bars | Steel Ck35, cylindrical, 3 shapes |
| Load cycle counter | Electronic, 8-digit display, switchable to speed |
| Speed sensing | Contactless inductive sensor |
About This Product
Students set the load with the hand wheel and spindle, start the motor and let the counter total the load cycles until the bar breaks and the stop switch ends the run. Comparing the plain bars with the specially shaped ones shows how notching and surface finish change fatigue life. The Fatigue Testing Machine can be dispatched from India to Japan, Somalia, Belarus, Guinea-Bissau and Mauritius.
Frequently Asked Questions
What happens when a test bar breaks?
A stop switch built into the movable support shuts the machine down automatically on fracture, and the electronic counter shows the load cycles on its 8-digit display.
What test bars are included?
Three sets of cylindrical test bars made of steel Ck35 in three different shapes, including special shapes that demonstrate the influence of notching and surface finish.
How is speed measured?
Through a contactless inductive speed sensor. The electronic load cycle counter can also be switched to display the speed.
Related: Mechanics Training Models, Creep Testing Machine, Vibrations On Machine Foundations.
For a quotation on the Fatigue Testing Machine, contact Educational Lab Equipments.
