Bar and Gauge Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10908
Quick Answer: Bar and Gauge is a 110 x 12.5 mm mild steel bar and a cast brass gauge, each with a wooden handle; the gauge has a 12.5 mm bore hole in both arms and slides over the ends of the bar.
Last updated: October 2026
Key Features
Mild steel bar, 110 x 12.5 mm.
Cast brass gauge.
Wooden handles on the bar and the gauge.
Hole of 12.5 mm bore in both arms of the gauge.
Gauge is a sliding fit over the ends of the bar.
Technical Specifications
Specification
Value
Bar
Mild steel, 110 x 12.5 mm
Gauge
Cast brass
Gauge holes
12.5 mm bore, both arms
Handles
Wooden, on both parts
Fit
Sliding fit over the bar ends
About This Product
The two parts are sized to each other: the ends of the steel bar pass through the 12.5 mm holes in the gauge arms as a sliding fit, and the wooden handles let each piece be held on its own.
Frequently Asked Questions
How do the bar and gauge fit together?
Both arms of the cast brass gauge have a 12.5 mm bore hole, and the gauge is a sliding fit over the ends of the 110 x 12.5 mm mild steel bar.
Do both parts have handles?
Yes. The bar and the gauge each have a wooden handle.
