Capillary Tube Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-PLE-10359
Quick Answer: The Capillary Tube Apparatus shows how capillary pressure relates to the bore of a tube. A 90 mm high metal frame holds six 150 mm capillary tubes of different bore above a 115 x 40 x 10 mm trough.
Last updated: October 2026
Key Features
Metal frame 90 mm high with a trough base of 115 x 40 x 10 mm.
6 holes in the frame fitted with corks.
Six capillary tubes of different bore, each 150 mm long.
Trough filled with water to show the difference in column heights.
Technical Specifications
Specification
Value
Frame height
90 mm
Trough
115 x 40 x 10 mm
Capillary tubes
6, different bores
Tube length
150 mm
Tube fixing
Corks in frame holes
About This Product
With water in the trough, the water stands at a different height in each tube, and the differences are easy to see. Lined up side by side, the six tubes make the link between bore diameter and capillary pressure clear at a glance. Educational Lab Equipments can supply and export the Capillary Tube Apparatus to Mongolia, Republic of the Congo, Tunisia, Albania, Estonia and Botswana.
Frequently Asked Questions
How many capillary tubes are fitted?
Six capillary tubes of different bore, each 150 mm long, held in corked holes in the metal frame.
What does the apparatus demonstrate?
The relationship between capillary pressure and the bore diameter of a capillary tube, seen as different heights of water in the tubes.
