Stereoscopic Zoom Binocular and Trinocular Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10387
Quick Answer: The Stereoscopic Zoom Binocular and Trinocular Microscope, as specified, has a 45 degree inclined trinocular head that rotates through 360 degrees, a quadruple nosepiece and a 135 x 120 mm graduated mechanical stage. A 6 V, 20 W halogen lamp and a mirror attachment allow working by lamp or daylight.
Last updated: November 2026
Key Features
Trinocular observation head inclined at 45 degrees and rotatable through 360 degrees.
Quadruple nosepiece with accurate centring and positive click stops.
Built-in graduated mechanical stage, 135 x 120 mm.
Low coaxial drive controls for smooth scanning of the slide over 50 x 75 mm.
6 V, 20 W halogen lamp for 220/110 V, plus a mirror attachment for daylight use.
Achromatic objectives 4X, 10X, 40X SL and 100X SL oil immersion.
Technical Specifications
| Specification | Value |
|---|---|
| Observation head | Trinocular, 45 degree inclined, 360 degree rotation |
| Nosepiece | Quadruple, positive click stops |
| Stage | Built-in graduated mechanical, 135 x 120 mm |
| Scanning range | 50 x 75 mm, low coaxial controls |
| Illumination | 6 V 20 W halogen, 220/110 V; mirror for daylight |
| Objectives | Achromatic 4X, 10X, 40X SL, 100X SL oil immersion |
About This Product
The low coaxial controls move the slide smoothly across a 50 x 75 mm range, and the click-stop nosepiece brings each objective into line in turn. As an alternative to the halogen lamp, the mirror attachment lets the instrument work by daylight.
Frequently Asked Questions
Which objectives are fitted?
Achromatic 4X, 10X, 40X SL and 100X SL oil immersion objectives on a quadruple nosepiece with click stops.
Can it be used without the lamp?
Yes. Besides the 6 V, 20 W halogen lamp for 220/110 V, it has a mirror attachment for working in daylight.
Which accessories suit the Stereoscopic Zoom Binocular and Trinocular Microscope for teaching and documentation?
A Digital Eyepiece Camera for capturing images, a Stage Micrometer for calibration, and prepared slides such as Chromosomes (400x) and Bacteria (1000x, gram stain) for demonstrations.
Who is the Stereoscopic Zoom Binocular and Trinocular Microscope suited to?
Laboratories and teaching departments that need to share or record what is seen, for example when one teacher demonstrates to a group, or when images are kept for reports and practical records.
Related: Microscopes, Binocular Stereo Zoom Microscope, Coaxial Trinocular Microscope, Trinocular Research Microscope.
For a quotation on the Stereoscopic Zoom Binocular and Trinocular Microscope, contact Educational Lab Equipments.
