Generation of Involute Gear Tooth Profile Manufacturer,Supplier and Exporter in India
Product Code : EL-TOMLE-11870
Quick Answer: The Generation of Involute Gear Tooth Profile board shows how involute gear teeth are cut by a rack-type cutter, tracing a module 25 mm tooth profile on paper placed between disc and cutter.
Last updated: October 2026
Key Features
Rack-type cutter generating involute teeth.
Gear tooth profile of module 25 mm traced on a piece of paper.
3 white acrylic discs, A, B and C.
Pitch circle diameters 450 mm, 300 mm and 200 mm.
Traced profiles show the effect of interference and undercutting.
Technical Specifications
Specification
Value
Cutter
Rack type
Module
25 mm
Discs
3, white acrylic (A, B, C)
Pitch circle diameters
450 mm, 300 mm, 200 mm
About This Product
With paper placed between the disc and the cutter, the tooth outline is traced from the rack, reproducing the cutting of an involute tooth on a drawing. Comparing profiles from the three discs shows how interference and undercutting affect the correct tooth shape. Colleges and TVET centres in Benin, Samoa, Ghana, Argentina, Suriname and Bhutan can source the Generation of Involute Gear Tooth Profile from Educational Lab Equipments.
Frequently Asked Questions
What sizes of disc are included?
Three white acrylic discs, A, B and C, with pitch circle diameters of 450 mm, 300 mm and 200 mm respectively.
What can be studied from the traced profiles?
The effect of interference and undercutting on the correct profile of the gear tooth.
