Hydraulic Steel Worker Manufacturer,Supplier and Exporter in India
Product Code : EL-WEAWLM-11666
Quick Answer: The Hydraulic Steel Worker combines hole punching, shearing, bar cropping and notching stations on one machine, driven by a compact hydraulic unit housed low inside the frame. It comes with 10 punches and dies up to 38 mm, a toolkit and an operator instruction manual.
Last updated: October 2026
Key Features
Quick-change punch holder with positive keyway location for shaped tools.
Universal goose neck die holder up to 57 mm for punching flats, angles and channel.
Guarding on all stations and a key-switch to isolate the notching station.
Adjustable strokes with rules at the punch and shear ends; swing-away punch stripper.
1 m auto cut-length stop and tables with rules, plate guides and quick-release handles.
Hydraulic and electrical overload protection; halogen light on a magnetic base.
Technical Specifications
| Specification | Value |
|---|---|
| Stations | Hole punching, shearing, bar cropping, notching |
| Die holder | Universal goose neck, up to 57 mm |
| Punches and dies | 10, up to 38 mm |
| Cut length stop | 1 m, automatic |
| Foot pedals | 2, movable |
| Overload protection | Hydraulic and electrical |
| Supplied with | Toolkit, operator instruction manual |
About This Product
A steel worker brings several fabrication operations together, so flats, angles and channel can be punched, sheared, cropped and notched without moving to other machines. Adjustable hold-down plates on the punching, shearing and cropping stations keep the work steady, and the 2 foot pedals can be moved to suit the operator. The Hydraulic Steel Worker can be dispatched from India to Egypt, Bangladesh, Fiji, South Africa and Poland.
Frequently Asked Questions
What sections can the Hydraulic Steel Worker punch?
Its universal goose neck die holder, up to 57 mm, takes punching of flats, angles and channel. The machine is supplied with 10 punches and dies up to 38 mm.
How is the notching station isolated?
A key-switch isolates the notch station, and guarding is fitted on all stations.
What is supplied with the machine?
A toolkit and operator instruction manual, 10 punches and dies, a halogen light on a magnetic base and 2 movable foot pedals.
Related: Welding Equipment and Workshop Lab Machine, Electric Shear, Pillar Drill Machine, Tube Bending Machine.
For a quotation on the Hydraulic Steel Worker, contact Educational Lab Equipments.
