Michelson Interferometer Manufacturer,Supplier and Exporter in India
Product Code : EL-TWL-11807
Quick Answer: The Michelson Interferometer carries three scales, including a 0–150 mm linear scale on its bed and a graduated slow-motion drum, and its mirror holders take mirrors of 25.4 mm diameter and 12.5 mm thickness. Fringes are viewed through a telescope with 10x magnification.
Last updated: October 2026
Key Features
Linear scale 0–150 mm, graduated in mm, fixed to the bed.
Graduated slow-motion drum (0–100 divisions) on the right-hand side.
Graduated disc (0–100 divisions) read through a glass window at the head; one division equals 0.01 mm.
Mirror holders with mirror mounts for mirrors of 25.4 mm diameter and 12.5 mm thickness.
Front-surface coated mirrors, 25 mm diameter and 10 mm thick, with 90% reflectivity.
Fringe-viewing telescope with an achromatic doublet objective of 125 mm focal length.
Technical Specifications
| Specification | Value |
|---|---|
| Linear scale | 0–150 mm, 1 mm graduations |
| Slow-motion drum | 0–100 divisions |
| Graduated disc | 0–100 divisions, 0.01 mm per division |
| Mirrors | Front-surface coated, 25 mm dia, 10 mm thick, 90% reflectivity |
| Mirror holder capacity | 25.4 mm dia, 12.5 mm thick |
| Telescope objective | Achromatic doublet, 25 mm dia, 125 mm focal length |
| Telescope magnification | 10x |
About This Product
Turning the slow-motion drum moves a mirror and shifts the interference pattern, which is watched through the telescope while the bed scale, drum and disc record how far the mirror has travelled. The mirrors are coated on the front surface, with the second face optically polished.
Frequently Asked Questions
What scales does the interferometer have?
Three: a 0–150 mm linear scale graduated in mm on the bed, a graduated slow-motion drum of 0–100 divisions on the right-hand side, and a 0–100 division graduated disc at the head, read through a glass window, with 0.01 mm per division.
What size mirrors fit the holders?
The holders, fitted with mirror mounts, accept mirrors of 25.4 mm diameter and 12.5 mm thickness. The front-surface coated mirrors listed are 25 mm in diameter and 10 mm thick, with 90% reflectivity.
How are the fringes observed?
Through a telescope whose objective is an achromatic doublet of 25 mm diameter and 125 mm focal length, giving 10x magnification.
