Coaxial Binocular Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-M-10377
Quick Answer: The Coaxial Binocular Microscope has a binocular head inclined at 45 degrees with 55 to 75 mm interpupillary and diopter adjustment, above a 115 x 125 mm rectangular stage with a coaxial mechanical stage. Variable 6 V 20 W halogen lighting is built into its box-type base.
Last updated: November 2026
Key Features
Binocular head inclined at 45 degrees.
Interpupillary distance 55 mm to 75 mm, with diopter adjustment.
Rectangular 115 x 125 mm stage with coaxial mechanical stage.
Box-type base with variable 6 V 20 W halogen illumination.
Rack and pinion sub-stage Abbe condenser, N.A. 1.25, with iris diaphragm and filter.
Achromatic objectives 4x, 10x, 40x and 100x (SL).
Technical Specifications
| Specification | Value |
|---|---|
| Head | Binocular, 45 degree inclined |
| Interpupillary distance | 55 to 75 mm, diopter adjustment |
| Stage | Rectangular 115 x 125 mm, coaxial mechanical stage |
| Illumination | 6 V 20 W halogen, variable, box-type base |
| Condenser | Abbe, N.A. 1.25, rack and pinion, iris and filter |
| Objectives | Achromatic 4x, 10x, 40x, 100x (SL) |
| Eyepieces | Huygenian 5x (pair), WF 10x (pair) |
About This Product
Intended for schools, colleges and research institutes, the microscope adjusts to each viewer through its interpupillary and diopter settings. The four achromatic objectives run from 4x up to 100x, and the variable halogen lamp with an iris-equipped condenser lets the light be set for each one.
Frequently Asked Questions
Which objectives are included?
Achromatic objectives of 4x, 10x, 40x and 100x (SL).
Which eyepieces are supplied?
A pair of 5x Huygenian eyepieces and a pair of 10x WF eyepieces.
What is the interpupillary range?
The binocular head adjusts from 55 mm to 75 mm and also has diopter adjustment.
What else is useful with the Coaxial Binocular Microscope in a college or clinical lab?
A Stage Micrometer for calibrating the eyepiece scale, prepared slides such as Artery, Vein & Nerve (400x) and Bacteria (1000x, gram stain), and a Slide Holder for storing slides.
How should the Coaxial Binocular Microscope be cleaned and stored?
Switch off and let the lamp cool, wipe oil from the 100x objective with lens tissue, lower the stage, set the lowest-power objective in place and fit the dust cover.
