Brake Roller Bench Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11361
Quick Answer: The Brake Roller Bench tests a roller brake in a 1300 mm storage channel: a pallet loaded with up to 50 kg runs along the two-rail track at a slope set from 0 to 6 degrees.
Last updated: October 2026
Key Features
Storage channel 1300 mm long, made of two rails, fitted with a roller brake.
Slope adjustable from 0 to 6 degrees in 1 degree steps.
Pallet can be loaded with masses up to 50 kg.
Strain-gauge sensor for normal and tangential force at the pallet-roller contact.
Speed sensors for the roller drum's rotation and the pallet's travel.
Technical Specifications
Specification
Value
Channel
1300 mm long, two rails
Slope
0 to 6 degrees, 1 degree steps
Pallet load
Up to 50 kg
Force sensor
Strain gauge, normal and tangential force
Speed sensors
Roller drum rotation, pallet translation
About This Product
Measuring the contact forces together with both speeds lets students analyse the dynamic contact between roller and pallet and see how the brake performs under working conditions. Changing the slope and the load shows how each one affects braking.
Frequently Asked Questions
What can be varied on the bench?
The slope of the channel, from 0 to 6 degrees in steps of 1 degree, and the load on the pallet, with masses up to 50 kg.
Which sensors are fitted?
A strain-gauge sensor for the normal and tangential force at the pallet-roller contact, a rotational speed sensor on the roller drum and a translation speed sensor on the pallet.
