Temperature Control Training System Stand Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11403
Quick Answer: The Temperature Control Training System Stand uses an aluminium heated bar, a Peltier element and a fan so students can study a thermal process under P, PI, PID and switching control.
Last updated: October 2026
Key Features
Aluminium heated bar as the controlled process.
Peltier element and a fan rated at 40 cubic metres per hour.
Temperature sensor and thermometer, each covering 0–100 degrees C.
Basic unit with a USB port.
Controller software for P, PI, PID and switching control.
Technical Specifications
Specification
Value
Process
Aluminium heated bar
Thermal element
Peltier element
Fan flow rate
40 cubic metres per hour
Temperature sensor
0–100 degrees C
Thermometer
0–100 degrees C
Basic unit
USB port
Controller software
P, PI, PID and switching
About This Product
Students begin with the open-loop response of the heated bar and the basics of temperature control. They then close the loop and compare how changing the controller method and its parameters alters the response, running the controllers from software connected through the USB port.
Frequently Asked Questions
Which control modes can be tried on this stand?
The software covers P, PI and PID control and switching control, so the closed-loop response under each method and with different parameters can be compared with the open-loop response.
What are the temperature ranges of the sensor and thermometer?
Both cover 0–100 degrees C. The process is an aluminium heated bar with a Peltier element and a fan rated at 40 cubic metres per hour.
