Universal Governor Apparatus Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11382
Quick Answer: The Universal Governor Apparatus lets students fit Watt, Porter, Proell or Hartnell governor mechanisms in turn on one motor-driven vertical spindle and read sleeve lift on a graduated scale.
Last updated: October 2026
Key Features
Four interchangeable governor mechanisms: Watt, Porter, Proell and Hartnell.
Stainless steel main spindle mounted vertically on the base plate.
Variable-speed FHP motor on the same base, with speed control panel.
Graduated scale on the sleeve to measure its displacement.
Governor mechanisms supplied with spring and weights.
Technical Specifications
Specification
Value
Governors
Watt, Porter, Hartnell, Proell
Spindle
Stainless steel, vertical
Motor
Variable speed FHP
Power supply
230 V AC, single phase
Floor space
1.5 x 1.5 m
About This Product
With one governor mounted at a time, the spindle speed is raised in steps and the sleeve displacement noted at each speed, with a tachometer giving the RPM. Comparing readings from the four mechanisms on the same rig shows how each type responds to a change in speed. Educational Lab Equipments can supply and export the Universal Governor Apparatus to Timor-Leste, Botswana, Philippines, Belgium, Kiribati and Madagascar.
Frequently Asked Questions
Which governors can be tested?
Four types: Watt, Porter, Hartnell and Proell. Any one governor assembly can be mounted on the spindle at a time.
How is speed set and measured?
The spindle speed is set on the speed control unit; a tachometer is needed to find the RPM.
How is sleeve movement measured?
A graduated scale fitted to the sleeve measures its displacement.
