DC Compound Motor And Generator Trainer Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11317
Quick Answer: The DC Compound Motor And Generator Trainer is a portable steel set with a control board and electric machine assembly for experiments on shunt, series and compound DC motors and generators. The control board carries an auto starter, four MCCBs, DC meters and a digital speed meter.
Last updated: October 2026
Key Features
Starting method and speed control of a shunt motor.
Load characteristics of shunt, series and compound motors.
No-load characteristics of a shunt generator; load characteristics of shunt and compound generators.
DC motor construction, winding resistance measurement and forward/reverse operation.
Shunt motor efficiency by the loss separation method.
Control board with auto starter, 4 MCCBs, 2 DC voltmeters, 2 DC ammeters and a digital speed meter.
Technical Specifications
Specification
Value
Power
Single phase AC
MCCB
4
DC voltage meters
2
DC ampere meters
2
Speed measurement
Digital speed meter with speed detector
Auto starter
1 set
DC power supply
1 set
Style
Steel, portable
About This Product
One machine set is used for both motor and generator work, so students can compare shunt, series and compound connections directly. The speed detector and digital speed meter supply the readings needed for the load characteristic curves, and loss separation is used to work out shunt motor efficiency.
Frequently Asked Questions
Which machine connections can be studied on the DC Compound Motor And Generator Trainer?
Load characteristics of shunt, series and compound motors, and no-load and load characteristics of shunt and compound generators.
What power does the control board need?
It runs on single phase AC and has a power lamp, four MCCBs, an auto starter and a DC power supply.
How is motor efficiency found?
The efficiency of the shunt motor is measured by the loss separation method.
