Spindle Moulder Machine Manufacturer,Supplier and Exporter in India
Product Code : EL-WWPT-11685
Quick Answer: The Spindle Moulder Machine cuts profiles with cutters on a 30 mm spindle that tilts to 45 degrees and runs at 5000 or 7000 rpm. A 5 HP motor drives it, and a 1300 mm sliding table works beside the 865 x 548 mm fixed table.
Last updated: October 2026
Key Features
30 mm spindle with 100 mm of up and down movement.
Spindle tilts up to 45 degrees.
Spindle speeds of 5000 and 7000 rpm.
Fixed table 865 x 548 mm plus a sliding table 1300 mm long and 315 mm wide.
Takes moulding blocks up to 100 mm wide.
100 mm dust extraction port.
Technical Specifications
Specification
Value
Spindle diameter
30 mm
Spindle speed
5000, 7000 rpm
Spindle up/down movement
100 mm
Spindle tilt
45 degrees
Max moulding block width
100 mm
Fixed table
865 x 548 mm
Sliding table
1300 mm long, 315 mm wide
Motor
5 HP
Dust extraction port
100 mm diameter
Machine dimensions (L x B x H)
1550 x 1200 x 1200 mm
Weight
400 kg
About This Product
A cutter block on the spindle shapes mouldings and edge profiles as the workpiece is guided across the tables. Raising, lowering and tilting the spindle sets the position and angle of the cut, and the sliding table carries the work past the cutter in a controlled line.
Frequently Asked Questions
Can the spindle be tilted?
Yes. It tilts up to 45 degrees and can be raised or lowered through 100 mm.
How large and heavy is the machine?
It measures 1550 x 1200 x 1200 mm (L x B x H) and weighs 400 kg.
What size dust extraction connection does it have?
