Basic PLC Unit with Power Supply Manufacturer,Supplier and Exporter in India
Product Code : EL-EELE-11406
Quick Answer: The Basic PLC Unit with Power Supply is a console-mounted PLC with a built-in 24 V/6 A DC supply, 8 analog inputs and 4 analog outputs, linked by PROFINET and PROFIBUS interfaces.
Last updated: October 2026
Key Features
Stable console on slip-resistant bases.
Integrated 24 V/6 A DC power supply; runs from 220–240 V AC, 50–60 Hz.
PROFINET IO with a 2-port switch as the standard interface, plus a second PROFINET interface and a PROFIBUS interface.
Built-in web server for reading configuration and operating data in a web browser.
8 analog inputs (-10 to +10 V and 0–20 mA) and 4 analog outputs, each selectable as -10 to +10 V or 0–20 mA.
Expandable with communications modules for bus systems and point-to-point links.
Technical Specifications
| Specification | Value |
|---|---|
| Power supply | 24 V / 6 A DC, integrated |
| Operating voltage | 220–240 V AC, 50–60 Hz |
| Standard interface | PROFINET IO, 2-port switch |
| Further interfaces | PROFINET, PROFIBUS |
| Analog inputs | 8; -10 to +10 V and 0–20 mA |
| Analog outputs | 4; -10 to +10 V or 0–20 mA, selectable |
About This Product
With analog channels in both voltage and current form, the unit can read sensor signals and drive actuators in a single set-up. Its web server opens configuration and operating data in an ordinary browser, and the communication modules extend it to bus networks and point-to-point links as a course moves on to industrial networking.
Frequently Asked Questions
What analog signals can the unit handle?
It has 8 analog inputs that accept -10 to +10 V and 0–20 mA, and 4 analog outputs that can each be set to -10 to +10 V or 0–20 mA.
How can system data be viewed?
A built-in web server gives access to the configuration data and the operating data relevant to the system through a web browser.
What supply does it need?
It operates from 220–240 V AC at 50–60 Hz and has a fully integrated 24 V/6 A DC power supply.
