Data Acquisition Card Manufacturer,Supplier and Exporter in India
Product Code : EL-TWL-11832
Quick Answer: The Data Acquisition Card connects real-world signals to a PC through the USB bus, with 4 analog inputs, 2 analog outputs and 22 digital inputs and outputs on removable screw terminals.
Last updated: October 2026
Key Features
4 analog inputs and 2 analog outputs.
22 digital inputs and outputs.
Two unity gain amplifiers to strengthen weak sensor signals.
Multifunction pins: the user can change inputs and outputs as needed.
Removable screw terminals.
USB control from a PC with user-friendly software; users can also write their own.
Technical Specifications
Specification
Value
Analog inputs
4
Analog outputs
2
Digital I/O
22
Amplifiers
Two, unity gain
PC interface
USB
Connections
Removable screw terminals
About This Product
Weak sensor signals pass through the unity gain amplifiers, and the multifunction board is controlled from the PC over USB. Students can work with the user-friendly software or write their own programs to read inputs and drive outputs for a process. Colleges and TVET centres in Gabon, Brunei, Sudan, Namibia, Iran and Georgia can source the Data Acquisition Card from Educational Lab Equipments.
Frequently Asked Questions
Can I write my own software for the card?
Yes. Besides the user-friendly software, users can create their own programs to control the board from a PC over USB.
How many channels does it have?
4 analog inputs, 2 analog outputs and 22 digital inputs and outputs, with pin functions the user can change.
