Emulsion Polymerization Reactor Manufacturer,Supplier and Exporter in India
Product Code : EL-TWL-11793
Educational Lab Equipments is a leading Emulsion Polymerization Reactor Manufacturer,suppliers and Exporter in India
Emulsion Polymerization Reactor
Description:-
The emulsion is of the type: oil in water, the monomer is oil soluble & the initiator is water-soluble & an emulsifier is used to create a stable emulsion.
Air has to be evacuated using a vacuum pump to create vacuum up to 30mm of Hg before passing the nitrogen supply.
Initiator from the reservoir is supplied to the reactor under pressure.
Polymerization is carried out under the atmosphere of air free nitrogen.
Apparatus can be used to generate the kinetic data for emulsion polymerization under various operating conditions like temperature, emulsifier concentration etc.
The set-up is used to carry out the emulsion polymerization involving polymerization of an unsaturated monomer like Styrene.
Metered quantity of nitrogen gas from a cylinder passes through a de-oxygenation column & allowed to enter the reactor.
The set-up is complete & self-contained with sampling ports.
The set-up consists of jacketed type SS reactor fitted with a variable speed agitator & baffles.
Hot water from a digitally controlled water bath is circulated in the jacket using a pump.
Experimentation:-
The parameter studies are conducted involving studies of:
Effect of RPM on conversion
Effect of emulsifier concentration.
Effect of Initiator concentration.
Effect of monomer concentration
Utilities Required:-
Water Supply.
Floor Drain.
Instruments, Laboratory wares, and Chemicals required for analysis as per the system adopted.
Electricity-1.5kw, Single.
Vacuum Pump.
High purity N2 gas.
