Disc Sander Manufacturer,Supplier and Exporter in India
Product Code : EL-WWM-11717
Quick Answer: The Disc Sander takes 12-inch PSA discs and is driven by a 1 HP, 110 V single-phase TEFC motor at 1725 RPM. Its 8-1/4 x 17-1/4 inch cast aluminium table tilts from 0 to 45 degrees and comes with a mitre gauge.
Last updated: October 2026
Key Features
Accepts 12 in PSA abrasive discs.
1 HP, 110 V, single-phase, 10 A TEFC motor at 1725 RPM.
Cast aluminium table 8-1/4 x 17-1/4 in, tilting 0–45 degrees, with mitre gauge.
Cast iron base with built-in 2 in dust port.
Non-slip rubber feet and toggle on/off switch.
Compact and fully portable.
Technical Specifications
Specification
Value
Disc
12 in PSA
Motor
1 HP, 110 V, single phase, 10 A, TEFC
Speed
1725 RPM
Table
8-1/4 x 17-1/4 in, cast aluminium
Table tilt
0–45 degrees
Base
Cast iron, built-in dust port
Dust port
2 in
About This Product
Small workpieces rest on the table and are pressed against the spinning disc to sand ends, edges and angles, with the mitre gauge holding the angle and the tilting table giving bevels. The built-in 2-inch port in the base takes the dust away from the disc. The Disc Sander can be dispatched from India to Equatorial Guinea, Sudan, Honduras, Japan, Croatia and France.
Frequently Asked Questions
What size sanding discs does it use?
12-inch PSA discs.
Does the table tilt?
Yes. The 8-1/4 x 17-1/4 inch cast aluminium table tilts from 0 to 45 degrees, and a mitre gauge is provided.
What power supply does it need?
110 V single phase; the 1 HP TEFC motor draws 10 A.
