CNC Semi Production Mill
Description:-
Semi Production Mill machine specially
designed with industrial controller.
This machine which is specifically designed
for educational institutes offers hands-on experience of industrial machines
with safety features of trainer machines.
Specification:-
Axis Motor and Drive |
Servo Motor with Servo Drives |
X Axis |
300 mm |
Y Axis |
225 mm |
Z Axis |
250 mm |
Spindle to column distance |
270 mm |
Feed Rate |
0 to 10,000 mm/min |
Rapid Travel |
10,000 mm/min |
Guideways |
LM Guideways |
Table Size |
560 x 220 mm |
T Slot |
3 x 10 x 50 |
Load on Table |
120 Kg |
Spindle Motor Capacity |
3 HP |
Spindle RPM |
100 to 4000 RPM |
Positioning |
0.010 mm |
Repeatability |
+- 0.005 mm |
Resolution |
0.001 mm |
Tool Changer |
Automatic |
No. of Tools |
8 / 12 |
Maximum Tool Length / Dia |
40 mm / 16mm |
Vice Type |
Pneumatic/ Manual |
Dimension in mm |
1300 x 1100 x 1900 mm |
